Barite Supplier & Exporter — API 13A Drilling Grades and White Barite Powder

BaSO₄ Barium Sulfate · SG 4.10 – 4.40

API 13A drilling barite at specific gravity 4.20 and 4.10, and high-brightness white barite powder at 95% BaSO₄ for paint, plastics and rubber. Independently tested to API 13A and NISOC methods, shipped in bulk or jumbo bags with a batch-specific Certificate of Analysis.

Request a Barite Quote Packaging & Incoterms
Bulk barite (barium sulfate, BaSO4) drilling-grade weighting agent and white barite powder — B2B export supplier Raivaco SG ≥ 4.20

Supply capability at a glance

4.21 g/cm³

Tested density, API 13A grade

25 MT

MOQ — bagged (1 × 20ft)

7–14 days

Lead time, standard grades

Per batch

Certificate of Analysis

Physical Properties

Formula

BaSO₄

Molecular Weight

233.39 g/mol

CAS No.

7727-43-7

Specific Gravity

4.10 – 4.40

Mohs Hardness

3.0 – 3.5

Solubility

Insoluble in water

Synonyms: Baryte, Barytes, Barium Sulfate, Heavy Spar, Drilling Mud Additive · Chemically inert, non-combustible solid; white to off-white powder or lump.

Grades & Chemical Analysis

Four barite grades — two API drilling weights and two chemical / filler grades. Select a grade to view its full analysis; every shipment includes a certificate of analysis.

Drilling grades tested to API 13A and NISOC laboratory methods under ISO/IEC 17025 accreditation. Values are typical specification ranges; a batch-specific CoA is issued per shipment.

Bespoke Production

Need a different specific gravity or mesh?

If none of the grades above matches your target chemistry, fineness, or packaging, tell us your requirements — we produce custom grades to your exact specification.

Request a Custom Grade

Applications

Barite earns its place two ways — extreme density for drilling and radiation shielding, and chemical inertness for fillers and pigments.

Oil & Gas Drilling Fluids

Weighting agent controlling formation pressure in water and oil-based muds.

Paints & Coatings

Inert extender giving body, opacity and chemical resistance.

Plastics & Rubber

Density and stiffness filler in masterbatch and compounds.

Radiation Shielding Concrete

High-density aggregate for medical and nuclear walls.

Barium Chemicals

Feedstock for barium carbonate, chloride and hydroxide.

Automotive Friction Products

Filler in brake pads and clutch linings.

Glass & Ceramics

Fluxing and brightening agent in specialty glass.

Paper Coating

Filler and coating pigment for high-gloss grades.

Medical Contrast Media

Refined barium sulfate for radiographic imaging.

Packaging, Logistics & Trading Terms

How we package, certify and ship bulk barite. Terms can be adapted by agreement — tell us what your operation needs.

Minimum Order Quantity
1 × 20 ft container (approx. 25 MT) bagged. 500 MT minimum for bulk vessel. Trial quantities available for qualification.
Packaging
Bulk, 1–1.5 MT woven jumbo bags (single or four-loop), or 25 kg / 50 kg PP bags. Lump supplied in bulk or jumbo bag.
Incoterms & Loading Ports
EXW, FOB, CFR and CIF (Incoterms® 2020). Standard loading at Bandar Abbas and Bandar Imam Khomeini; other ports by arrangement.
Quality Certification
Batch-specific CoA with every shipment covering specific gravity, sieve residue, soluble alkaline earth metals and clay content, tested to API 13A. SGS / Bureau Veritas inspection at buyer’s cost.
Lead Time
7–14 days for standard grades after order confirmation; 15–25 days for custom-milled or specially packed material.
Storage & Handling
Store dry and covered. Barite is chemically inert and non-combustible with no shelf-life limit, but caking is possible if bags take on moisture. Avoid generating dust when handling — the ore contains a small crystalline silica fraction.

Certificate of Analysis

A batch-specific CoA is issued with every shipment. Third-party inspection by SGS, Bureau Veritas or an inspector of your choice can be arranged at the buyer’s cost.

Ready to quote

Send us your grade, tonnage, destination port and packaging and we will return a firm FOB/CFR/CIF price with lead time.

Request a Barite Quote

Barite — Frequently Asked Questions

Does your drilling barite meet API 13A?
Yes. Our 4.20 grade is tested against API 13A and NISOC methods by an ISO/IEC 17025 accredited laboratory. A representative certificate shows density 4.21 g/cm³, residue on No. 200 sieve 2.04 %wt against a 3 %wt limit, soluble alkaline earth metals as calcium 160 ppm against a 250 ppm limit, and clay content 2.75 lb/bbl against a 3 lb/bbl limit.
What is the difference between 4.20 and 4.10 barite?
Specific gravity, and therefore how much mud weight you get per sack. The 4.20 grade is the standard API 13A drilling weight; the 4.10 grade is an economy weighting agent for shallower wells or where mud weight requirements are lower. The 4.10 material carries a higher iron and silica fraction, which is why its barium content is lower.
Which barite grade suits paint and plastics?
The white barite powder. It runs 95.18% BaSO₄ with 91% whiteness, specific gravity minimum 4.40 and iron below 0.04%, so it will not discolour a light-coloured system. For a barium chemicals feedstock the high-purity lump at 63.81% BaO is the right starting material.
How is barite packed and shipped?
Bulk, 1–1.5 MT woven jumbo bags, or 25 kg / 50 kg PP bags. Powder grades are normally jumbo-bagged; lump ships in bulk. Standard loading is FOB Bandar Abbas, with CFR and CIF available to most destination ports.
What is the minimum order quantity for barite?
One 20 ft container, approximately 25 MT, for bagged material. Bulk vessel shipments start at 500 MT. Trial quantities can be arranged so you can qualify the material before a full order.
Are there handling precautions for barite?
Barite itself is chemically inert and insoluble. However, natural barite ore contains a small crystalline silica (quartz) fraction, so avoid generating airborne dust, use local exhaust ventilation where dust is likely, and wear a NIOSH-approved dust mask when handling loose material. A full MSDS is issued with every shipment.

Related Products

Bentonite The viscosifier that pairs with barite in water-based drilling mud. Calcium Carbonate Acid-soluble bridging agent and low-density filler alternative.
